Flow Switch, Grid Controls 2' M310 TEE 10A Flow Switch, Chemical Dosing Control, for Pump
- Useful in the following applications: Water treatment systems, Aquarium, water chiller plants, chemical dosing, pump control Pump Systems Blending or Additive Systems Liquid Transfer Systems Fire Sprinkler Systems Water Treatment Systems Solar systems Pool cleaning systems Irrigation systems
Quantity
-
Detail
To use with pumps and heaters. The flow switch has a 10A microswitch that provides closed dry contact when there is a water flow and open contact when there is no water flow. Wiring is required by a licensed electrician. If you prefer prewired, please check prewired option listed on our website. Micro Switch Rating: 10A Maximum 230V Turn On at and above 25 GPM flow. Turn off at and below 20 GPM flow. 2" PVC Inlet and outlet spigot connections, Glue type, insert flow switch into 2" pipe socket and glue it. Wetted Surfaces - PVC, Polypropylene, Buna N, SS304 Line Pressure: 90 PSI Temperature: Up to 110 deg F Underwriters Laboratories recognized. 10A dry contact. 1/2" Electrical Conduit Connection
-
