Linear Optical Ruler KA300 Linear Optical Ruler Linear Scale 5U 5V TTL Dimensions 70 120 170 220 270 320 370 420 470(KA300-420)
- Mechanical toughness and corrosion resistance.
- Widely used in grinding machines, lathes, milling machines, spark machines, rifling machines, wire cutting, etc.
- measurement and digital display ruler displacement sensor, data is accurate and stable.
- Using transmission and optical measurement good performance.
- Great workmanship and assurance, high safety factor, can be used with peace of mind.
Quantity
-
Detail
5U 5V TTL KA-300 Parameter
Linear scale parameter
1. Travel (measuring) length: 70-470mm
2. Total (overall) length: Travel length + 106mm
3. DB9
4. Resolution: 0.005mm
5. Input voltage: 5V
6. Grating pitch: 0.02mm (50LP/min)
7. Cable length: 3 Meter (about 9 feet)
8. Normal size: About 34.5*25 -
